Garage Door V Strut Forming Machine
Garage Door V Strut Forming Machine
Garage Door V Strut Forming Machine

Garage Door V Strut Forming Machine



Payment Type: L/C,T/T

Incoterm: FOB,CFR,EXW,CIF

Min. Order: 1 Set/Sets

Transportation: Ocean

Port: shanghai

sales@cxrollformer.com

Tel: 008613357917888

Whatsapp: 8613357917888

Garage Door V Strut Forming Machine
Garage Door V Strut Forming Machine
description1
Zipper closure 1/4 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout
Overview

Product Attributes

Brand: Chuangxu

Status: New

Applicable Industry: Building Material Shops

Where To Provide Local Services (in Which Countries Are There Overseas Service Outlets): Canada, Egypt, Brazil, Peru, Saudi Arabia, Turkey, United Kingdom, United States, Italy, India, Mexico, France, Germany, Russia, Spain, Morocco, Kenya, Chile, South Africa

Showroom Location (in Which Countries Are There Sample Rooms Overseas): Canada, Egypt, Brazil, Peru, Turkey, Saudi Arabia, United Kingdom, United States, Italy, India, Mexico, France, Germany, Russia, Spain, Kenya, Chile, South Africa, Morocco

Core Components: Plc

Out-of-warranty Service: Online Support



Supply Ability & Additional Information

Transportation: Ocean

Place of Origin: China

Port: shanghai

Payment Type: L/C,T/T

Incoterm: FOB,CFR,EXW,CIF



Packaging & Delivery

Selling Units: Set/Sets

Main Technical Data



NO.

name

quantity

Main roll former



1

Un-coiler (2 tons ) MANUAL

1

2

roll former

1

3

Hydraulic cutter

1

4

PLC control cabinet

1

5

Output table with rollers(6 meters)

1
Technical Details

Un-coiler

  1. Capacity: 2 tons
  2. Material: #45 steel quenched
  3. Inner diameter: 410~ 580mm

Main roll former

  1. Stations: 12
  2. Rollers material: CR 15;HRC 60. chrome coated: 0.03~0.05mm. the Strength in Mpa :70 TON,800 MPA
  3. Shaft material: Diameter: 40mm, material is #45 steel. Quenched: hot treatment. The strength of the Main Shaft in Mpa:70 tons, 650MPA
  4. Bearing brand: FAG Germany
  5. Main Motor: 5.5 KW, 380V, 50HZ



CHAMICAL COMPOSITION:



C

SI

MN

P

S

CR

NI

CU

MO

AI

V

B

Shaft

0.450

0.220

0.540

0.027

0.008

0.050

0.020

0.010

0.000

0.009

0.000

0

Rollers

1.00

0.32

0.33

0.011

0.003

1.49

0.05

0.00

0.02

0.041





Cutter

1.57

0.34

0.38

0.022

0.010

11.10

0.18

0.14

0.48







Cut knife

2.04

0.23

0.23

0.020

0.010

11.66

0.12

0.06









PLC Control Cabinet:

  1. Touch screen brand: Delta
  2. PLC brand: Delta
  3. Inverter brand: Delta
  4. Main components for low pressure electricity: Schneider Germany



Output table

  1. Length: 6 meters
  2. Drive type: Rollers



CUTTING PLATFORM

  1. Cutting type: Hydraulic Fly cutter with servo control system
  2. Motor: 4KW; 380V; 50HZ
  3. Material of cut die: CR12MOV; Quenched; the Strength in MPA: 950
